Cement silo Constmach Silo à Ciment d'une Capacité de 1000 Tonnes

You can call us 24/7 for a 1000 ton cement silo for sale.

Our CS-1000 model cement silo with a capacity of 1000 tons is an ideal option for those who are looking for high performance and durability. This model, which has a silo height of 20840 mm and a diameter of Ø 8250 mm, stands out with its large storage capacity. the silo, which stands on 8 solid steel pipe legs, has a total weight of 72000 kg. CS-1000, each component of which is carefully selected, is made of high-quality ST-37 steel materials.

The internal and external manhole structure of the silo ensures trouble-free unloading of the material. With an outlet diameter of Ø 300 mm and steel tube feet of Ø273 x 10 mm, it offers maximum stability. In addition, it has the possibility of safe use with the maintenance platform and roof arrests.

Each silo is specially produced according to approved projects and structure analysis is carried out. Anticorrosive protection is provided by applying three coats of paint and offers a long-lasting use with a total paint thickness of 140 microns. Thanks to these features, the CS-1000 model silo is the priority choice of those who are looking for a reliable and efficient storage solution. With its superior quality and durability, it takes your business one step further.

Technical Specifications of CS-1000 - 1000 Ton Cement Silo

Silo Capacity 1.000 tons

Silo Height 20840 mm

Silo Diameter Ø 8250 mm

The Number of Silo Feet is 8

Silo Outlet Diameter Ø 300 mm

Number of Components 191

Silo Weight 72000 kg

Silo Foot Material Ø273 x 10 mm steel pipe

Silo Foot Supports 100 mm C channel

Silo Foot Plates 25-30 mm

Taper Part Support Material 160 mm steel C channel

Conical Part Material ST-37, 10 mm metal sheet

Silo Body Material ST-37, 8 - 6 - 5 mm metal sheet

Silo Top Cover Material ST-37, 5 mm metal sheet

Charging Pipe 4" steel pipe up to the silo leg

Internal Manhole is available

External Man Hole is available

The Silo Roof is included in the arrests

The Maintenance Platform is available

Structure Analysis is carried out for silos and the production process is carried out depending on the approved projects

Painting 1 layer of anticorrosive paint, 2 layers of top coat epoxy paint, total paint thickness 140 microns
